200重型快速废钢剪切机主要技术参数：

200 main technical parameters of heavy speed scrap shearing machine:

1、剪切刀长：1米。

1, cutting knife length: 1 meters.

2、剪切油缸规格：剪切油缸内径200-205毫米，剪切力可达100吨左右。

2, shearing cylinder specifications: shearing cylinder diameter 200-205 mm, shear force of up to 100 tons.

3、电机配置：18.5千瓦电机或22千瓦电机。

3, motor configuration: 18.5 kilowatt motor or 22 kilowatt motor.

4、高压油泵规格：100YCY或者160YCY高压柱塞泵。

4, high pressure oil pump specification: 100YCY or 160YCY high pressure plunger pump.

5、剪切最大张口尺度：剪切最大张口为350毫米到400毫米。

5, shear maximum opening scale: the maximum shear opening is 350 mm to 400 mm.

6、剪切速度：每分钟8-10次剪切速度。

6. Shear speed: 8-10 shear speeds per minute.

7、剪切废钢种类：槽钢、工字钢、煤矿小道轨、角钢、汽车拆解大梁、螺纹钢、船板、普板厚度30毫米，圆钢直径600-700毫米等都可剪切。剪切厚度越厚剪切宽度越窄。

7, shear type: scrap steel, steel, coal, steel, automobile dismantling rail track girder, steel, shipbuilding, Pu plate thickness of 30 mm, 600-700 mm in diameter can be cut. The thicker the shear thickness, the narrower the shear width is.

（1）采用液压驱动，操作方便，维修简单。适用范围广，工作效率高、主机即可以安装于室内也可以安装在室外。

(1) the use of hydraulic drive, easy operation, simple maintenance. A wide range of application, high efficiency, the host can be installed in the room and can be installed in the outdoor.

（2）工作刀口长度：500mm-1200mm,剪切力从60吨至250吨。适用不同规模，不同要求用户选择。

(2) work blade length: 500mm-1200mm, shear force from 60 tons to 250 tons. It is suitable for different sizes and requires users to choose.

（3）安装无须底脚螺丝，无电源的地方可用柴油机作动力。

(3) no foundation bolts for installation, where the available diesel engine without power supply for power.

安全操作规程:

Safe operation procedure:

(1)设备应定人操作，其他人未经培训不得任意使用。

(1) the equipment should be operated by person, and other people should not be used without training.

(2)开车前应检查各部位是否正常，紧固件是否牢固。

(2) check whether the parts are normal before driving, and the fasteners are firm.

(3)禁止剪切未经退火的钢件、铸铁件、软质金属件、过薄的工件、长度小于100毫米的工件，以及超过剪刀长度的工件。

(3) it is forbidden to cut unannealed steel, iron castings, soft metal parts, over thin workpieces, workpiece with a length less than 100 millimeters, and workpiece that exceeds the length of scissors.

(4)操作时，人体不准接近设备的传动部分及刀口，并应注意周围人员的安全，防止料翘起伤人。剪切时应尽量将料靠近刀里边剪切。剪较短料时，不得用手持工件送料，应采用夹钳送料。

(4) when operation, the human body is not allowed to close the transmission part of the equipment and the knife edge, and should pay attention to the safety of the surrounding people, prevent the material to rise and hurt people. When cutting, the material should be cut near the edge of the knife as far as possible. When cutting short material, it should not be delivered with hand-held workpiece, and the clamp should be used.

(5)设备运转时，操作人员不得擅自离开岗位，工作完毕或暂离岗位时，应切断电源。

(5) when the equipment is running, the operator shall not leave the post without permission, and the power supply shall be cut off when the work is completed or the post is temporarily off.

安装前准备工作：

Preparatory work before installation:

用户准备380伏电压及170-200kg液压油（46#）建议使用原装品牌的液压油如长城牌、昆仑牌、中石油牌、中石化牌等，做好以上准备工作即可接电按装投入生产。（注：北方夏季32#冬季46#；南方冬夏季均用46#）

The user will prepare 380 volt voltage and 170-200kg hydraulic oil (46#). It is recommended to use the original brand of hydraulic oil such as the Great Wall brand, Kunlun brand, CNPC and Sinopec brand. (Note: northern summer 32# winter 46#; southern winter and summer in the use of 46#)
